1.    High degree of automation: intelligent program temperature control, automatic detection, automatic alarm and automatic switching. Users can be selected according to the sintering process requirements of different PTFE products. Power, heating elements and control system in sintering process, when a fault occurs, can automatically detect the fault and display and alarm, if the installation of standby system, once there is a fault in the alarm at the same time, the device will continue to run to the standby system on automatic switching, 100% to ensure the quality of sintered products.

2.    Record of sintering process: the instrument and instrument are also equipped with output ports, which can realize multiple sintering furnaces to run and sinter at the same time. At the same time, a paper or paperless recorder can be connected to record and track the whole process of sintering, and to show the actual working temperature in the furnace.

3.    The temperature uniformity is high: the unique hot air circulation system and large wind volume match, and the high quality insulation system and innovative gate design ensure the temperature uniformity of each point in the furnace and the low external surface temperature of the furnace.

4.    The cleanliness is good: the inner and the heating elements of the box are all made of stainless steel, and the air filters can be put into / exported to prevent the dust in the outside air from entering the furnace due to PTFE static electricity, which ensures the cleanliness of the box.

5.    The quality is stable and reliable: the blower motor, impeller and electric heating are all made of high temperature resistant materials, which can adapt to the continuous work of 24 hours per day without stopping. The quality is stable and reliable, the noise is small, and the furnace body is not jitter.

6.    Maintenance and maintenance is convenient: fans, electric heaters and other accessories are standardized and modular according to different sintering furnaces structure, so that faults can be judged more accurately, and fittings maintenance is more convenient and timely.

7.    The structure is flexible: the hot air cycle can be chosen according to the properties and shapes of the sintered products and the configuration of the bottom trolley system in the process of loading and unloading

Technical parameters (non - standard production)
