Product features

1、The insulation part of the furnace body is filled with domestic high-quality aluminum silicate cotton, aluminum silicate cotton blanket and ceramic fiberboard. It has excellent energy-saving type, low surface temperature and good characteristics of energy saving and consumption reduction.

The ceramic fiber cotton we use is a loose fiber formed by electrofusion, blowing or wire throwing without secondary processing and heat treatment.

Ceramic fiber textile cotton.

The ceramic fiber mold board we use is made of ceramic fiber cotton and vacuum formed,

Made after special treatment. The product has uniform structure and good heat resistance,

Suitable for engraving molds.

Ceramic fiber fire baffle is a high-strength fiber plate produced with specific fire-resistant additives. This product has tough texture, high compressive strength, superior high-temperature resistance and excellent support; It can be used as an excellent refractory for fire prevention and heat insulation in the temperature range of industrial kiln.

The ceramic fiber machine-made board and fire deflector formula we use contains a small amount of organic binder to enhance its cold strength

Degree, and the organic matter can be reduced when burned for the first time at about 200 ℃ to 300 ℃.

2、The tank, rotary table and heating elements of the box are made of stainless steel, which can ensure the cleanliness of the box even if the equipment operates for a long time;

3、The intelligent temperature controller controls the temperature, with PID self-tuning and SSR solid-state relay power regulation, so as to ensure better temperature fluctuation in the box;

4、The touch screen is used for centralized control, which can pre store multiple temperature control curves, track and record temperature data in the whole process, remotely monitor the operation of sintering furnace, and the mobile phone receives alarm information in case of abnormal conditions.

5、Flexible and diverse air supply modes can be selected, and the unique hot air circulation system and large air volume design ensure the temperature uniformity of all points in the furnace; Fan blade forward, reverse, forward and reverse installation interaction and air volume adjustment. Different sintering products can be used flexibly and selected in many ways.

6、The unique thermal insulation system and gate design create excellent thermal insulation performance and achieve the best energy-saving and consumption reduction standard for customers;

7、The front observation window is designed to make the drying process of products in the box clearly visible;

8、The workpiece can be placed by rotating material tray, trolley material rack and fixed porous material tray. Good ventilation and heavy load.

technical parameter
